Abov MC96F6432S Series User Manual

136
MC96F6432S
ABOV Semiconductor Co., Ltd.
11.7.7 Timer/Counter 2 Register Description
The timer/counter 2 register consists of timer 2 A data high register (T2ADRH), timer 2 A data low register (T2ADRL),
timer 2 B data high register (T2BDRH), timer 2 B data low register (T2BDRL), timer 2 control high register (T2CRH)
and timer 2 control low register (T2CRL).
11.7.8 Register Description for Timer/Counter 2
T2ADRH (Timer 2 A data High Register): C5H
7
6
5
4
3
2
1
0
T2ADRH7
T2ADRH6
T2ADRH5
T2ADRH4
T2ADRH3
T2ADRH2
T2ADRH1
T2ADRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T2ADRH[7:0]
T2 A Data High Byte
T2ADRL (Timer 2 A Data Low Register): C4H
7
6
5
4
3
2
1
0
T2ADRL7
T2ADRL6
T2ADRL5
T2ADRL4
T2ADRL3
T2ADRL2
T2ADRL1
T2ADRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T2ADRL[7:0]
T2 A Data Low Byte
NOTE)
1. Do not write “0000H” in the T2ADRH/T2ADRL register when PPG
mode.
T2BDRH (Timer 2 B Data High Register): C7H
7
6
5
4
3
2
1
0
T2BDRH7
T2BDRH6
T2BDRH5
T2BDRH4
T2BDRH3
T2BDRH2
T2BDRH1
T2BDRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T2BDRH[7:0]
T2 B Data High Byte
T2BDRL (Timer 2 B Data Low Register): C6H
7
6
5
4
3
2
1
0
T2BDRL7
T2BDRL6
T2BDRL5
T2BDRL4
T2BDRL3
T2BDRL2
T2BDRL1
T2BDRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T2BDRL[7:0]
T2 B Data Low Byte
