11.5.8 Register Description for Timer/Counter 0
T0CNT (Timer 0 Counter Register): B3H
7
6
5
4
3
2
1
0
T0CNT7
T0CNT6
T0CNT5
T0CNT4
T0CNT3
T0CNT2
T0CNT1
T0CNT0
R
R
R
R
R
R
R
R
Initial value: 00H
T0CNT[7:0]
T0 Counter
T0DR (Timer 0 Data Register): B4H
7
6
5
4
3
2
1
0
T0DR7
T0DR6
T0DR5
T0DR4
T0DR3
T0DR2
T0DR1
T0DR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T0DR[7:0]
T0 Data
T0CDR (Timer 0 Capture Data Register: Read Case, Capture mode only): B4H
7
6
5
4
3
2
1
0
T0CDR7
T0CDR6
T0CDR5
T0CDR4
T0CDR3
T0CDR2
T0CDR1
T0CDR0
R
R
R
R
R
R
R
R
Initial value: 00H
T0CDR[7:0]
T0 Capture Data
