Page #24 background imageLoading...
Page #24 background image
24
MC96F6432S
ABOV Semiconductor Co., Ltd.
PIN
Name
I/O
Function
@RESET
Shared with
RESETB
I/O
System reset pin with a pull-up resistor when it is
selected as the RESETB by CONFIGURE OPTION
Input
P55
DSDA
I/O
In-system programming data input/output
Input
P00/EC3
DSCL
I/O
In-system programming clock input
Input
P01/T3O
XIN
I/O
Main oscillator pins
Input
P51
XOUT
P50
SXIN
I/O
Sub oscillator pins
Input
P53/T0O/PWM0O
SXOUT
P54/EINT10
VDD,
VSS
Power input pins
Table 5.5 Normal Pin Description (continue)
NOTE)
1. The P14P17, P23P25, P34P37, and P43 are not in the 32-pin package.
2. The P13P17, P22P27, P34P37, and P43 are not in the 28-pin package.
3. The P55/RESETB pin is configured as one of the P55 and RESETB pin by the CONFIGURE OPTION.
4. If the P00/EC3/DSDA and P01/T3O/DSCL pins are connected to the programmer during power-on reset,
the pins are automatically configured as In-system programming pins.
5. The P00/EC3/DSDA and P01/T3O/DSCL pins are configured as inputs with internal pull-up resistor
only during the reset or power-on reset.
6. The P50/XOUT, P51/XIN, P53/SXINT/T0O/PWM0O, and P54/SXOUT/EINT10 pins are configured as
a function pin by software control.
