Abov MC96F6432S Series User Manual

77
MC96F6432S
ABOV Semiconductor Co., Ltd.
P4OD (P4 Open-drain Selection Register): 94H
7
6
5
4
3
2
1
0
–
–
–
–
P43OD
P42OD
P41OD
P40OD
–
–
–
–
R/W
R/W
R/W
R/W
Initial value: 00H
P4OD[3:0]
Configure Open-drain of P4 Port
0
Push-pull output
1
Open-drain output
P4FSR (Port 4 Function Selection Register): EFH
7
6
5
4
3
2
1
0
–
P4FSR6
P4FSR5
P4FSR4
P4FSR3
P4FSR2
P4FSR1
P4FSR0
–
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
P4FSR6
P43 Function Select
0
I/O Port(SS0 function possible when input)
1
VLC0 Function
P4FSR[5:4]
P42 Function Select
P4FSR5
P4FSR4
Description
0
0
I/O Port
0
1
VLC1 Function
1
0
SCK0 Function
1
1
Not used
P4FSR[3:2]
P41 Function Select
P4FSR3
P4FSR2
Description
0
0
I/O Port
0
1
VLC2 Function
1
0
TXD0/SDA0/MOSI0 Function
1
1
Not used
P4FSR6[1:0]
P40 Function Select
P4FSR1
P4FSR0
Description
0
0
I/O Port
0
1
VLC3 Function
1
0
RXD0/SCL0/MISO0 Function
1
1
Not used
