6146/6156 DC Voltage/Current Generators Operation Manual
5.8.3 Remote Command List
5-41
Calibration
Calibration exe-
cution
XS0 Positive polarity (HI limit for limiter calibration)
XS1 Negative polarity (LO limit for limiter calibration)
XS? Query of the positive/negative calibration mode
Response: XS0 or XS1
XN0 Zero calibration
XN1 Full calibration
XN? Query of the zero/full calibration mode
Response: XN0 or XN1
XM0 Normal source mode
XM1 DMM input mode
XM? Query of the calibration mode
Response: XM0 or XM1
Calibration data
save (RAM to
ROM)
XWR Saves the calibration data in the non-volatile memory.
Calibration data
initialization
(RAM)
XINI Initializes the calibration data.
• Not initializes the calibration data in the non-volatile
memory.
XCLR Initializes the calibration data such as currently selected
function, range and polarity.
• Not initializes the calibration data in the non-volatile
memory.
Calibration data
input
XDT
±ddddE±d
DMM read data input
DAC
Calibration exe-
cution
(6156 only)
XK1 ym0 calibration (DMM input mode)
XK2 ym1 calibration (DMM input mode)
XK3 ym10 calibration (DMM input mode)
XK4 ym11 calibration (DMM input mode)
XK5 ym12 calibration (DMM input mode)
XK6 ymi1 calibration (DMM input mode)
XK7 ymi2 calibration (DMM input mode)
XK8 ymi3 calibration (DMM input mode)
XK9 ymi4 calibration (DMM input mode)
XK10 ymi5 calibration (DMM input mode)
XK11 ymi6 calibration (DMM input mode)
XK12 ymi7 calibration (DMM input mode)
Class Item Command Description
Default Operation
Power
ON
Factory
shipment
Memory Sweep
