6146/6156 DC Voltage/Current Generators Operation Manual
2.3.1 Memory Recall Mode
2-42
The following sections describe the procedures assuming that the memory data below has been set.
2.3.1.2.1 Executing Hold Scan
1. Press PRGM MODE once on the HOME screen to set the memory recall mode.
The source value of memory number 0 is recalled.
If the program mode is switched in Operate status, the output status will become
Standby.
Example using the 6156
2. Press SCAN MODE several times to set the hold scan mode. (The "HOLD" indi-
cator goes ON.)
In this example, the hold scan mode has been already set.
When the hold scan mode is set, "HoLd" is displayed for about a second.
3. Press OPR to set the output status to Operate.
Memory number Function Range Source value
0 Voltage 3 V 1.0 V
1 Voltage 3 V 1.1 V
2 Voltage 3 V 1.2 V
3 Voltage 3 V 1.3 V
4 Voltage 3 V 1.4 V
5 Initial value (+0.0 mV in 30 mV range)
Cursor (blinking)
Cursor (blinking)
