6146/6156 DC Voltage/Current Generators Operation Manual
2.3.2 Sweep Source Mode
2-47
4. Move the cursor onto the start value with .
Example using the 6156
5. Change the value with , , , or .
6. Changing the decimal point position
Move the cursor onto the decimal point position with or , and change
it with , or .
7. Changing the unit
Move the cursor onto the unit position with or , and change it with ,
or .
The unit changes in either of the following orders:
pV / nV / μV / mV / V / kV / MV / GV / TV
pA / nA / μA / mA / A / kA / MA / GA / TA
Press ENTER and EXIT in this order to return to the HOME screen.
Direct data input using DATA is also available.
The start, stop step and bias values are always saved in the optimum range.
Setting the stop value
The stop value is set using MENU, SWEEP and STOP.
Set the stop value in the same manner as the start value.
Setting the step value
The step value is set using MENU, SWEEP and STEP.
Set the step value in the same manner as the start value.
Cursor (blinking)
Cursor (blinking)
Cursor (blinking)
To Next Page
