BRAKES
SPECIFICATIONS
General Specifications
Front Brake Drum
Item Standard Service Limit
Brake Shoe Thickness 2.54 mm (0.10”) 1.27 mm (0.05”)
Brake Drum Inner Diameter 85.09 mm (3.35") 84.33 mm (3.32")
Rear Brake Disc
Item Standard Service Limit
Brake Pad Thickness 5 mm (0.20”) 2 mm (0.08")
Brake Disc Thickness
4.2 mm (0.17”) 3.8mm (0.15”)
Torque Specifications
Item Torque
(Nm)
Torque
(ft. lbs. except where noted*)
Brake Arm Retaining Bolts 4.9 43 in. lbs.
Axle Housing Flange Nuts or
Brake Plate Bolts
54 40
Chain Guard Bolts 22 16
NOTE: Refer to the tightening procedures in this chapter when torquing the bolts. Some special procedures
are used when torquing certain bolts and fasteners.
7.2
