ENGINE / TRANSMISSION
Flywheel Removal / Inspection
1. Remove the flywheel cover, the flywheel nut, and washer.
Install flywheel puller and remove flywheel.
CAUTION: Do not hammer or strike the tool or
crankshaft may be damaged.
Stator Removal
1. Remove flywheel.
2. Loosen stator screws (A) and pulse coil screws (B) evenly
and remove stator. Note wire routing for assembly.
B
Stator Inspection
Visual inspect the isolation of coil and pulse coil wires.
Measure resistance value of each stator leg.
the DC resistance value is 720~ 850.
Negative Positive
4.11
A
