BODY / SUSPENSION / STEERING

SUSPENSION

Front Shock Removal

1. Elevate front end of the ATV off the ground to remove

shock spring tension.

Severe injury could occur if machine tips or falls.

2. Remove the upper shock mounting bolt from the frame and

the lower shock mounting bolt from the front suspension arm /

A-arm.

3. Replace the shock or spring as required.

4. Install shock as shown in Figure 5.8.

5. Torque shock mounting bolts to specification.

Front Shock Mounting Bolt Torque:

34 Nm (25 ft. lbs.)

6.5
