BODY / SUSPENSION / STEERING
FRONT A
-
ARM
A-arm Exploded View
A-arm Replacement
1. Elevate front end of ATV off the ground far enough to
remove the wheel.
Severe injury could occur if machine tips or falls.
2. Remove the dust cap and cotter pin.
3. Remove wheel nut and remove wheel and hub as an
assembly.
4. Remove the cotter pin from the upper spindle castle nut and
remove the nut.
5. Slide the spindle assembly out from the end of the control
arm.
6.7
