ENGINE / TRANSMISSION
Engine Lubrication
Oil Type:**
2T/ LST
Capacity: Approximately 1000ml (30 oz.)
Transmission Lubrication
Oil Type:
80W/ 90 API
Capacity: Approximately 350 ml (12 oz.)
Drain Plug (Transmission): 16 ft. lbs. (21.5 Nm)
ENGINE DISASSEMBLY
CYLINDER HEAD DISASSEMBLY
1. Loosen all four bolts of cylinder head cover.
2. Remove cylinder head cover.
3. Thoroughly clean cylinder head surface to remove all
traces of gasket material and carbon.
4. Remove the cylinder head gasket.
Stud bolt
Use care not to damage sealing surface. If there is
damage found on the cylinder head combustion
chamber, it is recommended the component be
replaced.
Cylinder head gasket
5. Tap cylinder lightly with a plastic hammer in reinforced
areas only until loose.
4.6
