5.10

FUEL SYSTEM

4. Remove the pilot jet , main jet , and from the carb body.

2. Remove cable with valve from the carb body.

5. Note the position of both the air mixture screw and idle

speed adjustment screw and remove both from the carb body.

3. Loosen the choke seat screw.

Throttle Valve and Choke Disassembly

1. Loosen the cable nut and valve cover.

4. Remove

whole choke with cable then take apart as

following .
