BODY / SUSPENSION / STEERING
5. Remove the 2 bolts attaching the body to the footwells
on each side.
6. Remove the 8 screws attaching front and rear cabs to the
footwells on each side.
9. Disconnect both front indicator plugs.
7. Remove the 2 bolts attaching the body to the front cab
on each side.
10. Completely remove the front cab from body.
11. Remove 2 footwells from body.
12. Remove the 4 bolts of rear cab.
8. Disconnect the headlight harness.
13. Disconnect the taillight harness.
14. Remove the 2 bolts attaching the rear cabs then take off
taillight.
6.3
