AERMEC HMG - Technical Dimensions

23
TECHNICAL DIMENSIONS
1200
729
15
22
765
845
166
146
246
126 121
1340
1605
2200
2060
844
258 143
1675
851
880
965
22
15
HMG0350
HMG0600
B C D
A
Description
A
Unit fixing holes or holes for anti-
vibration positionin
B
Water inlet
C
Water drain tap
D
Water outlet
Description
E
Unit fixing holes or holes for anti-
vibration positioning
F
Water drain tap
G
Water inlet
H
Water oulet
E
F
G
H
(mm)
(mm)
