ELECTRIC BOARD ON BOARD THE UNIT
HMG0350
HMG0600
Description
1
Operating status output (230V)
2
Operating status output (neutral)
3
Alarm output (230V)
4
Alarm output (neutral)
5
Pump 1 contactor output (230V)
6
Pump 1 contactor output (neutral)
7
Pump 2 contactor output (230V)
8
Pump 2 contactor output (neutral)
9
ON / OFF clean contact input
10
11
Auxiliary electric heater 1 contactor output (230V)
12
Auxiliary electric heater 1 contactor output (neutral)
13
Auxiliary electric heater 2 contactor output (230V)
14
Auxiliary electric heater 2 contactor output (neutral)
1 5 93 7
11 13
2 6
10
4 8
12 14
1 5 93 7
12 14
2 6
10
4 8
13 15
Description
1
Operating status output (230V)
2
Operating status output (neutral)
3
Alarm output (230V)
4
Alarm output (neutral)
5
Pump 1 contactor output (230V)
6
Pump 1 contactor output (neutral)
7
Pump 2 contactor output (230V)
8
Pump 2 contactor output (neutral)
9
ON / OFF clean contact input
10
12
Auxiliary electric heater 1 contactor output (230V)
13
Auxiliary electric heater 1 contactor output (neutral)
14
Auxiliary electric heater 2 contactor output (230V)
15
Auxiliary electric heater 2 contactor output (neutral)
