46
NOTE
• The switch and power cord specifications listed in the
table above are determined based on the maximum
power (maximum amps) of the unit.
All electrical operations must be carried out by
personnel in possession of the necessary legal
requirements, trained and informed on the risks
associated with such operations.
• The characteristics of the electrical lines and related
components must be determined by personnel
qualified to design electrical systems, in compliance
with the international and national standards of the
place of installation of the unit in compliance with the
laws in force at the time of installation.
• For installation requirements, refer to the wiring
diagram supplied with the appliance. The wiring
diagram together with the manuals must be kept
carefully and made available for future work on the
unit.
• It is compulsory to check the watertight integrity of
the machine before making the electrical connections
and it must only be powered when the plumbing and
electrical work has been completed.
ELECTRICAL DATA
The cable sections shown in the table are recommended for
a maximum length of 50 m. For longer lengths or different
types of cable laying, it will be the designer's responsibility to
appropriately size the line switch, the power supply line and
the earth protection connection, and the connection cables in
operation:
• Of the length.
• Of the cable type.
• The absorption of the unit and the physical location, and the
ambient temperature.
Model
Power supply
Magnetothermic recom-
mended
Minimum recommended section
for power cables [EN60335 - 1]
(A) (mm²)
Phases Neutral Ground line
HMG0350 380-415V 3N ~ 50Hz 32 6 6 6
HMG0600 380-415V 3N ~ 50Hz 63 16 16 16
