25
MINIMUM TECHNICAL SPACES FOR SINGLE
UNIT
MINIMUM TECHNICAL CLEARANCES FOR
MODULAR UNITS
> 1200
> 1000> 1000
> 1000
> 3000
> 1200
> 1000> 1000
> 1000
(mm)(mm)
Air outlet
Electric box
Water inlet / outlet connections
>1000
>500
> 3000
> 500
> 1000
> 1000
> 1000
> 1000
> 1000
> 1000
> 500
> 500
> 1200
> 1200
> 1200
> 1000
(mm)
>1000
>500
> 3000
> 500
> 1000
> 1000
> 1000
> 1000
> 1000
> 1000
> 500
> 500
> 1200
> 1200
> 1200
> 1000
(mm)
