48
Description
1
Secure the cable with a clamp or cable tie
2
Secure the cable with a clamp or cable tie
3
Secure the cable on both sides of the vertical column
with clamps or cable ties
4
The pre-cut hole, after all wiring and electrical
connection work on the unit have been carried out, must
be sealed to prevent the entry of foreign covers that
could damage the cables and components.
Description
5
Secure the cable with a clamp or cable tie
6
The pre-cut hole, after all wiring and electrical
connection work on the unit have been carried out, must
be sealed to prevent the entry of foreign covers that
could damage the cables and components.
HMG0350
HMG0600
1
2
3
4
5
6
