1106 Display Fusing
1106 1 Displays the fusing temperature (center)
1107*
Fusing Soft Start
Adjusts the number of zero-cross cycles of the fusing lamp AC supply needed to bring the
fusing lamp
power to 100% while bringing the lamp up to the standby temperature or while
copying. Increase this value if the machine is experiencing sudden power dropouts (
Fusing Temperature Control).
1107 1 Warm Up Soft Start [0 = 10 cycles / 1 = 20 cycles / 2 = 50 cycles]
1107 2 Other Soft Start [0 = 5 cycles / 1 = 10 cycles / 2 = 20 cycles]
1108* Set-Fusing Start [0 = 1s / 1 = 1.5s / 2 = 2s]
1108 1 Specifies the interval for fusing-temperature control ( Fusing Temperature Control).
1109 Nip Band Check
1109 1 Checks the fusing nip band ( NIP Band Width Adjustment).
1110* Fan Control Timer
1110 1
[30 to 60 / 30 / 1 s/step]
Inputs the fan control time. The fan maintains normal speed for the specified time after
occurrence of
an SC or following entry into Warm-up mode, Low Power mode, or Night/
Off mode.
1159* Fusing Jam SC Code Setting 0=No 1=Yes
1159 1
This SP mode detects SC559. Set this SP mode to 'Yes' if the machine experiences paper
jam problems on a continual basis.
1902 Display-AC Freq.
1902 1
Displays the fusing lamp power control frequency (as detected by the zero cross signal
generator). The displayed value is 1/5 the actual frequency: 10 = 50 Hz, 12 = 60 Hz.
SP Mode Tables
31
