Agilent Technologies 1100 Series - Page 37

1100 Series DAD and MWD User Manual 37
LAN Configuration 3
Figure 10 Using Stored (Principle)
Using Default
When “Using Default” is selected, the factory default parameters are taken
instead. These parameters enable a TCP/IP connection to the LAN interface
without further configuration, see Table 7.
Figure 11 Using Default (Principle)
Since the default IP address is a so-called local address, it will not be routed by
any network device. Thus, the PC and the detector must reside in the same
subnet.
Active
Parameter
Non-Volatile
RAM
Stored
Parameter
Default
Parameter
Active
Parameter
NOTE
Using the default address in your local area network may result in network problems. Take
care and change it to a valid address immediately.
Table 7 Using Default Parameters
IP address: 192.168.254.11
Subnet Mask: 255.255.255.0
Default Gateway not specified
