1290 Infinity II High-Speed Pumps User Manual 149
8Maintenance
Replace the Solvent Selection Valve (SSV)
5 Install a new SSV by inserting the connector and clip-
ping the SSV panel to the module top panel. Then rein-
stall all tubing connections, and open the shutoff valves.
A2
A1
B1
B2
A
B
A
B
