1290 Infinity II High-Speed Pumps User Manual 246

10 Identifying Cables

USB

To connect a USB Flash Drive use a USB OTG cable with Mini-B plug and A

socket.

p/n Description

5188-8050 USB A M-USB Mini B 3 m (PC-Module)

5188-8049 USB A F-USB Mini B M OTG (Module to Flash Drive)
