1290 Infinity II High-Speed Pumps User Manual 67
3Using the Pump
Setting up the Pump with the Instrument Control Interface
The Pump User Interface (Dashboard Panel)
Module Graphic
The items in the pump graphic have the following meaning and function:
The current solvent flow rate (in mL/min) is displayed above the pressure display.
Indicates that an External Contacts board is installed.
The level of solvent in the bottle is denoted by the green area; when the sol-
vent level falls below the specified volume, the area turns yellow; when the
bottle is empty, the area turns red. Clicking on the solvent bottle displays the
Bottle Fillings dialog box. The tooltip for the bottle shows the solvent name.
Indicates that the ISET option is installed but with no active method (light
gray) or installed and active (dark gray).
Indicates the presence of a solvent selection valve. Click the graphic to
switch the valve; the animation shows when the valve is switched.
The pressure setpoints. The red line shows the current maximum pressure
limit; the gray area shows the current pressure (also shown as text).
