Agilent Technologies 35670A - Page 142

Channel Match
Two Ch, 2/1, 7 dBV FS Mag
−0.04
0.04
Two Ch, 2/1, 7 dBV FS Phs
−0.5
0.5
Two Ch, 2/1, −13 dBV FS Mag −0.04
0.04
Two Ch, 2/1, −13 dBV FS Phs −0.5
0.5
Two Ch, 2/1, −33 dBV FS Mag −0.04
0.04
Two Ch, 2/1, −33 dBV FS Phs −0.5
0.5
Two Ch, 2/1, 7 dBV −20 dBfs Mag −0.08
0.08
Two Ch, 2/1, 7 dBV −20 dBfs Phs −0.5
0.5
Four Ch, 2/1, 7 dBV FS Mag
−0.04
0.04
Four Ch, 2/1, 7 dBV FS Phs
−0.5
0.5
Four Ch, 2/1, −13 dBV FS Mag −0.04
0.04
Four Ch, 2/1, −13 dBV FS Phs −0.5
0.5
Four Ch, 2/1, −33 dBV FS Mag −0.04
0.04
Four Ch, 2/1, −33 dBV FS Phs −0.5
0.5
Four Ch, 2/1, 7 dBV −20 dBfs Mag −0.08
0.08
Four Ch, 2/1, 7 dBV −20 dBfs Phs −0.5
0.5
Four Ch, 3/1, 7 dBV FS Mag
−0.04
0.04
Four Ch, 3/1, 7 dBV FS Phs
−0.5
0.5
Four Ch, 3/1, −13 dBV FS Mag −0.04
0.04
Four Ch, 3/1, −13 dBV FS Phs −0.5
0.5
Four Ch, 3/1, −33 dBV FS Mag −0.04
0.04
Four Ch, 3/1, −33 dBV FS Phs −0.5
0.5
Four Ch, 3/1, 7 dBV −20 dBfs Mag −0.08
0.08
Four Ch, 3/1, 7 dBV −20 dBfs Phs −0.5
0.5
Four Ch, 4/1, 7 dBV FS Mag
−0.04
0.04
Four Ch, 4/1, 7 dBV FS Phs
−0.5
0.5
Four Ch, 4/1, −13 dBV FS Mag −0.04
0.04
Four Ch, 4/1, −13 dBV FS Phs −0.5
0.5
Four Ch, 4/1, −33 dBV FS Mag −0.04
0.04
Four Ch, 4/1, −33 dBV FS Phs −0.5
0.5
Four Ch, 4/1, 7 dBV −20 dBfs Mag −0.08
0.08
Four Ch, 4/1, 7 dBV −20 dBfs Phs −0.5
0.5
Four Ch, 4/3, 7 dBV FS Mag
−0.04
0.04
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Four Channel
12 of 20
