Agilent Technologies 35670A Service Guide

To remove dc-dc converter
1 Remove front panel (see ‘’To remove front
panel’’). Remove A7 CPU assembly (see ‘’To
remove CPU’’).
2 Using a T-10 torx driver, remove the five
screws from the front wall.
3 Using a T-10 torx driver, remove the four
screws from the shield. Unplug ribbon cables.
4 Using a T-10 torx driver, remove the four
screws from the A102 DC-DC Converter assembly.
Replacing Assemblies Agilent 35670A
To remove dc-dc converter
6-18
