Agilent Technologies 35670A

Source Output
Source types Sine, random noise, chirp, pink noise, burst
random, burst chirp
Amplitude range
ac:
±5 V peak †
dc:
±10V†
† Vac
pk
+ |Vdc| ≤10 V
AC amplitude resolution
Voltage ≥ 0.2 Vrms
Voltage < 0.2 Vrms
2.5 mVpk
0.25 mVpk
DC offset accuracy
±15 mV±3% of ( |Vdc| +Vac
pk
) settings
Pink noise adder Add 600 mV typical when using pink noise
Output impedance
<5
Ω
Maximum loading
Current
Capacitance
±20 mA peak
0.01 mF
Sine amplitude accuracy at 1 kHz
Rload >250
Ω
0.1 Vpk to 5 Vpk
±4% (0.34 dB) of setting
Sine flatness (relative to 1 kHz)
0.1 V to 5 V peak, 0 Hz to 102.4 kHz
±1dB
Harmonic and sub-harmonic distortion and spurious signals (in band)
0.1 Vpk to 5 Vpk sine wave
Fundamental <30 kHz
Fundamental ≥30 kHz
<−60 dBc
<−40 dBc
Agilent 35670A Specifications
Source Output
1-11
