General Specifications
Safety Standards CSA Certified for Electronic Test and
Measurement Equipment per CSA C22.2, No.
231
This product is designed for compliance to:
UL1244, Fourth Edition
IEC 348, Second Edition, 1978
EMI/RFI Standards CISPR 11
Acoustics LpA <55 dB (cooling fan at high speed
setting)
<45 dB (auto speed setting at 25° C)
Fan speed setting of high, automatic, and off are available. The fan off setting can be enabled
for a short period of time, except at higher ambient temperatures where the fan will stay on.
Environmental operating restrictions Operating:
disk in drive
Operating:
no disk in drive
Storage and
transport
Ambient temperature 4° to 45° C 0° to 55° C –40° to 70° C
Relative humidity (non-condensing)
minimum
maximum
20%
80% at 32° C
15%
95% at 40° C
5%
95% at 50° C
Vibration (5 - 500 Hz) 0.6 Grms 2.1 Grms 3.41 Grms
Shock 5 G
(10 ms 1/2 sine)
5G
(10 ms 1/2 sine)
40 G
(3 ms 1/2 sine)
Maximum altitude 4600 meters (15,000 feet)
AC power 90 Vrms to 264 Vrms (47 to 440 Hz)
350 VA maximum
DC power 12 Vdc to 28 Vdc nominal
200 VA maximum
DC current at 12 V (typical) 10 A (standard)
12 A (4 channel, option AY6)
Warm-up time 15 minutes
Weight 15 kg (33 lb) net
29 kg (64 lb) shipping
Dimensions
(Excluding bail handle and impact cover)
Height: 190 mm (7.5 in)
Width: 340 mm (13.4 in)
Depth: 465 mm (18.3 in)
IEC 801-3 (Radiated Immunity) Performance degradation may occur at Severity Level 2.
Agilent 35670A Specifications
General Specifications
1-13
