To remove front panel
1 Remove cover (see ‘’To remove cover’’). 2 Remove assembly retainer bracket.
3 Slide A5 Analog assembly part way out and
disconnect gray mic cable.
4 Using a T-15 torx driver, remove the two
screws on each side of the front panel.
Replacing Assemblies Agilent 35670A
To remove front panel
6-8
