Agilent Technologies 35670A Service Guide

A8 Memory
The following table lists signals routed between the A8 Memory assembly and the
A7 CPU assembly. This table shows several things — if the assembly generates or
uses the signal or voltage, and if a signal is bidirectional. A description of each signal
follows the table.
Signal Name
A7 J3 Pin(s) A8 P1 Pin(s) A7 J3 A8 P1
BD16 25C C8
⇔⇔
BD17 25B B8
⇔⇔
BD18 26C C7
⇔⇔
BD19 26B B7
⇔⇔
BD20 26A A7
⇔⇔
BD21 27C C6
⇔⇔
BD22 27B B6
⇔⇔
BD23 27A A6
⇔⇔
BD24 28C C5
⇔⇔
BD25 28B B5
⇔⇔
BD26 28A A5
⇔⇔
BD27 29C C4
⇔⇔
BD28 29B B4
⇔⇔
BD29 29A A4
⇔⇔
BD30 30C C3
⇔⇔
BD31 30B B3
⇔⇔
CPUSPCn
17A A16 S •
DSACK0n
3A A30 • S
DSACK1n
4A A29 • S
FLASHEN
19A A14 S •
G20MHZ
32C C1 S •
MEMRESET
20A A13 S •
PA0
1C C32 S •
PA1
1B B32 S •
PA2
2C C31 S •
PA3
2B B31 S •
PA4
3C C30 S •
PA5
3B B30 S •
PA6
4C C29 S •
S This assembly is the source of the signal.
• This assembly uses the signal.
⇔ This signal is bidirectional.
Voltages and Signals Agilent 35670A
A8 Memory
9-8
