Agilent Technologies 35670A Service Guide

To set up the single channel phase accuracy test
Performance Test and Operation Verification
This test verifies that the Agilent 35670A meets its single channel phase accuracy
specification. In this test, a frequency synthesizer outputs an identical square wave
to all channels and a synchronized TTL-level signal to the trigger input. The phase
difference between the trigger and each channel is measured to determine phase
accuracy.
1 2ch
1 4ch
Verifying Specifications Agilent 35670A
To set up the single channel phase accuracy test
3-34
