Order Tracking — Option 1D0
Max Order Max RPM
60
×
≤
Real time (online)
1 channel mode
2 channel mode
4 channel mode
25,600 Hz
12,800 Hz
6,400 Hz
Capture playback †
1 channel mode
2 channel mode
4 channel mode
102,400 Hz
51,200 Hz
25,600 Hz
Specified for
5 ≤ RPM ≤ 60,000 (online), 5 ≤ RPM ≤ 491,519 (capture playback); and
number of orders ≤ 200
† Signals are captured online and then postprocessed in capture playback mode.
Delta order 1/128 to 1/1
Resolution
(maximum order)/(delta order)
≤200
Maximum RPM ramp rate
1000 to 10,000 RPM run up
maximum order = 10
delta order = 0.1
RPM step = 30 (1 channel)
= 60 (2 channel)
= 120 (4 channel)
750 RPM/second (typical for real time)
Order track amplitude accuracy
±1 dB (typical)
Specifications Agilent 35670A
Order Tracking — Option 1D0
1-14
