Agilent Technologies 35670A Service Guide

To set up the external trigger test
Performance Test only
This test verifies that the Agilent 35670A meets its trigger specification for external
trigger level accuracy. In this test, a frequency synthesizer outputs a 1 kHz signal
to the external trigger input and a 12.8 kHz signal to channel 1. The analyzer
makes an accurate triggered measurement on channel 1 to verify the trigger level
and slope.
1 2ch Using an HP 3326A
1 4ch Using an HP 3326A
Agilent 35670A Verifying Specifications
To set up the external trigger test
3-35
