To set up the tach function test
Performance Test and Operation Verification
This test is only for Agilent 35670A’s with option 1D0, computed order tracking.
This test verifies that the Agilent 35670A meets its tachometer specification for
trigger level accuracy. In this test, a frequency synthesizer outputs a signal to the
tachometer input and to channel 1. The analyzer makes an accurate order
measurement on channel 1 to verify the trigger level and slope.
1 2ch Using an HP 3326A
1 4ch Using an HP 3326A
Agilent 35670A Verifying Specifications
To set up the tach function test
3-37
