Tachometer
Pulses per revolution 0.5 to 2048
RPM accuracy
±100 ppm (0.01%) (typical)
Tachometer level range
Low range
High range
–4Vto+4V
–20 V to +20 V
Tachometer level resolution
Low range
High range
100 mV
500 mV
Tachometer level accuracy (as a % of
tachometer range setting)
±10% of range
Maximum tachometer input level
±42 Vpk
Minimum tachometer pulse width 600 ns
Maximum tachometer pulse rate 400 kHz
Specifications Agilent 35670A
Tachometer
1-10
