Agilent Technologies 35670A Service Guide

To set up the amplitude linearity test
Performance Test and Operation Verification
This test verifies that the Agilent 35670A meets its single channel amplitude
specification for FFT amplitude linearity at 1 kHz. In this test, the ac calibrator
outputs a 1 kHz signal with an an exact amplitude to all channels. This test checks
amplitude linearity at 27, 13, −1, −15, −29, −43, and −53 dBVrms.
1 2ch
1 4ch
Agilent 35670A Verifying Specifications
To set up the amplitude linearity test
3-19
