Agilent Technologies 35670A - Page 144

Frequency Accuracy
Measurement Lower Limit
(kHz)
Upper Limit
(kHz)
Measured Value
(kHz)
Pass/Fail
50 kHz
49.9985 50.0015
Anti-Alias Filter
Measurement Lower Limit Upper Limit
(dBfs)
Measured Value
(dBfs)
Pass/Fail
One Ch, Ch 1, 51.2 kHz
−80
Two Ch, Ch 1, 51.2 kHz
−80
Two Ch, Ch 2, 51.2 kHz
−80
Four Ch, Ch 1, 25.6 kHz
−80
Four Ch, Ch 2, 25.6 kHz
−80
Four Ch, Ch 3, 25.6 kHz
−80
Four Ch, Ch 4, 25.6 kHz
−80
Input Coupling
Measurement Lower Limit Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
dc - ac, Ch 1
3
dc - ac, Ch 2
3
dc - ac, Ch 3
3
dc - ac, Ch 4
3
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Four Channel
14 of 20
