Chapter 5 Straightness Measurements

Making Vertical Axis Straightness Measurements

5-18 Measurements Reference Guide

Figure 5-11. Assembling the reflector assembly for vertical measurements

Reflector

2 Reflector attachment

screws

3 Reflector mount

4 Reflector rotation screw

5 Reflector post

6 Reflector base
