Chapter 5 Straightness Measurements

Making Vertical Axis Straightness Measurements

Measurements Reference Guide 5-19

Figure 5-12. Assembling and attaching the turning mirror

Turning mirror

attachment screws

2 Turning mirror

3 Turning mirror base

4 Turning mirror base

attachment screw

0772

-6

ASSY
