Agilent Technologies 5530 User Manual

Chapter 4 Angular Measurements
Angular Position Measurements
Measurements Reference Guide 4-27
Figure 4-16B. Angular position measurements—principles (Part 2 of 2)
5
4 Table “engaged” position 5 Instruct Agilent 5530 calibrator to
collect data.
4a After base has rotated, provide 3.0 mm
closing movement to provide sufficient
engagement force between top and base.
Allow enough dwell time for measurement
data collection before beginning next
lift-rotate-lower cycle.
For remaining measurements, cycle
controlling axis between this position and
relative zero position.
For remaining measurements, repeat
step 2 through this step until all data
has been collected.
4b Table top engaged with base
0
10
20
350
30
40
50
60
70
80
90
100
110
340
330
320
4
Y
ZX
4a
4b
