Routine Maintenance: Inlets
Maintaining a PTV
Released: March 2004 6850 Series II GC User Information page 165 of 256
Consumables and replaceable parts
Table 31 lists orderable PTV parts.
Table 31. PTV Consumables and Replacement Parts
Description Quantity Part no.
Septumless head assembly 1 G2617-60507
Service kit 1 5182-9747
Valve body 1 5182-9757
Pressure spring 1 5182-9758
Kalrez seal 1 5182-9759
Teflon guide 1 5182-9748
Sealing element 1 5182-9760
GRAPHPACK-3D ferrule for liners 5 5182-9749
Assembly tool for GRAPHPACK-3D ferrules 1 G2617-80540
Single baffle liner 1 5183-2038
Single baffle liner 1 5183-2036
Multi baffle liner 1 5183-2037
Fritted glass liner 5183-2041
GRAPHPACK-2M inlet adapter, 0.2 mm column id 1 5182-9754
GRAPHPACK-2M inlet adapter, 0.32/0.25 mm column id 1 5182-9761
GRAPHPACK-2M inlet adapter, 0.53 mm column id 1 5182-9762
Silver seal for GRAPHPACK-2M inlet adapter 5 5182-9763
Nut for GRAPHPACK inlet adapters 5 5062-3525
Ferrules for GRAPHPACK-2M inlet adapter, 0.2 mm column id 10 5182-9756
Ferrules for GRAPHPACK-2M inlet adapter, 0.25 mm column id 10 5182-9768
Ferrules for GRAPHPACK-2M inlet adapter, 0.32 mm column id 10 5182-9769
Ferrules for GRAPHPACK-2M inlet adapter, 0.53 mm column id 10 5182-9770
Syringes
5 µL, 23 gauge fixed needle 1 9301-0892
10 µL, 23 gauge fixed needle 1 9301-0713
10 µL, Teflon-tipped plunger, 23 gauge fixed needle 1 5181-8809
10 µL, Teflon-tipped plunger, 23 gauge removable needle 1 5181-8813
25 µL, Teflon-tipped plunger, 23 gauge fixed needle 1 5183-0316
25 µL, Teflon-tipped plunger, 23 gauge removable needle
1 5183-0317
50 µL, Teflon-tipped plunger, 23 gauge fixed needle 1 5183-0318
50 µL, Teflon-tipped plunger, 23 gauge removable needle 1 5183-0319
Septa and seals
Merlin Microseal starter kit (cap + 1 microseal) 1 5182-3442
Merlin Microseal replacement 1 5182-3444
11-mm septa, red 25 5181-1263
