Agilent Technologies 6850 Series II User Manual

Automatic Liquid Sampler and Injector
Faults
Released: March 2004 6850 Series II GC User Information page 239 of 256
Faults
Four lights on the injector indicate its status (Figure 51).
During normal operation, the Ready light is on. If the injector is busy, the Run
light is on.
If another combination of lights are on, an error has occurred.
Use the following instructions to try to solve the problem before obtaining
Agilent service.
Figure 51. Injector status lights
No light is on
Probable causes
• The line voltage to the GC is off.
• The injector cable or connection to the GC is bad.
• Your GC requires service.
Suggested actions
1. Verify the injector is properly connected to the GC.
2. Check the power source for your GC.
3. Obtain Agilent service.
Align Mode light
Fault light
Run light
Ready light
