Agilent Technologies 6850 Series II - Installing a Sampler or Injector on the 6850 GC

Automatic Liquid Sampler and Injector
Installing a sampler or injector on the 6850 GC
Released: March 2004 6850 Series II GC User Information page 242 of 256
Installing a sampler or injector on the 6850 GC
Use Figure 52 to install the mounting post and the injector.
Figure 52. Installing the mounting post and mounting the injector
7
Mounting post,
G2613-20500
The 6850 Automatic Liquid Sampler and the
6850 Automatic Injector install in the same way.
The 6850 Automatic Injector is shown.
