Agilent Technologies 6850 Series II User Manual

Automatic Liquid Sampler and Injector
The 6850 automatic liquid sampler
Released: March 2004 6850 Series II GC User Information page 232 of 256
4. Remove the three mounting screws in the turret.
5. With the syringe door open, hold down the door open switch and press the
Align button.
The tray will rotate to the position shown here. Note the position of the roller
on the vial stripper arm relative to the turret.
Remove
three
screws
Door open switch
Align button
