4 Operating the 850-DS
850-DS Operator’s Manual 59
Option Description
Volume Calibration mL to Dispense Enter volume (in mL) to be collected in sample tubes / vials during the
volume calibration procedure.
Row Number Specify the row where the sample volume should be collected.
Actual mL Enter the average sample volume collected (in mL) during the volume
calibration procedure.
mL / Stroke Automatically calculated value based on volume calibration
parameters. This value is stored until the next volume calibration is
performed. No user entry is required/permitted.
Prime Primes (fills) the sample tubing lines prior to executing the volume
calibration procedure. This ensures the lines are sufficiently filled and
an accurate sample volume is collected.
Dispense Dispenses the programmed volume (in mL) into the specified row.
Pressing Dispense displays an onscreen dialog that guides the user
through the volume calibration process.
Figure 30.Volume
Calibration Pre-check
Figure 31.Volume
Calibration Completion
Stop Stops the volume calibration procedure.
