4 Operating the 850-DS
850-DS Operator’s Manual 73
Option Description
Collector Serial Number Manufacturer-assigned serial number.
LAN MAC Address MAC address that will be used for LAN communications.
Firmware Version Version of the firmware installed on the instrument.
Release Date Release date of the firmware.
Collector Name A 25-character field to describe the instrument.
Collector Comm ID A 2-digit numeric field that is used when a PC or other instrument is
communicating with the Agilent 850-DS.
Note: If multiple instruments are connected together, each unit must
have a unique Comm ID.
Prime Loss Volume The volume in mL that is pumped at the beginning of each sample
point. This volume represents the volume in the tubing between the
sample collector and the needles. Pumping this volume to the return
lines first ensures that the volume aspirated at the sample time is what
is actually delivered to the sample tubes / vials instead of the volume
remaining in the lines after prime.
Number Active Vessels Enter the number of active vessel positions on the dissolution
apparatus. This value is important if the vessel temperature start is
used.
Dissolution Apparatus Apparatus 1/2/5/6 Sets the operating mode to expect an Apparatus 1/2/5/6 instrument
to be connected to the Agilent 850-DS.
Apparatus 3/7 Sets the operating mode to expect an Apparatus 3/7 instrument to be
connected to the Agilent 850-DS.
Comm ID Communications ID of the attached Agilent dissolution apparatus.
Sample Format Test Tubes Indicates a rack holding an array of 8 x 12 test tubes or vials is installed.
Vial Blocks Indicates a rack holding two 9 x 6 blocks with 2 mL vials is installed.
Well Plate Indicates a rack holding two 96-position well plates is installed.
100-vial Tray Indicates a rack holding an array of 10 x 10 (offset spacing) for 2 mL
vials is installed.
