Service Guide 2-23
8719ET/20ET/22ET System Verification and Performance Tests
8719ES/20ES/22ES System Verification
RF Network Analyzers
NOTE For broadband measurements, use either a broadband load or a combination
of lowband (or broadband) and sliding loads. Use the same loads used during
normal calibrations.
9. Press either or
, depending on which device is used. If you
select , you must also measure a lowband load to complete the loads
calibration.
10.When the measurement is complete, press . Leave the load connected to
cable 1.
ES Models
11.If you are calibrating an ES analyzer, go to “Port 2 Calibration (ES Models),” on
page 2-23.
ET Models
12.If you are calibrating an ET analyzer, press .
13.The analyzer briefly displays COMPUTING CAL COEFFICIENTS.
14.Connect a load to the TRANSMISSION port and press .
After the isolation calibration completes, go to “Thru Calibration,” on page 2-24.
Port 2 Calibration (ES Models)
15.When the analyzer finishes measuring the standard, connect the open that is supplied
in the calibration kit to cable 2.
16.Press .
17.When the analyzer finishes measuring the standard, connect the short that is supplied
in the calibration kit to cable 2.
18.Press .
19.When the analyzer finishes measuring the standard, connect the 50Ω termination to
cable 2.
20.Press .
21.Press either or , depending on which device is used. If you
select , you must also measure a lowband load to complete the loads
calibration.
22.When the measurement is complete, press .
Leave the load connected to cable 2.
23.The analyzer briefly displays COMPUTING CAL COEFFICIENTS.
24.Press .
25.After the isolation calibration completes, go to “Thru Calibration,” on page 2-24.
