Agilent Technologies 8719ET Service Guide

Service Guide 2-47
8719ET/20ET/22ET System Verification and Performance Tests
8719ES/20ES/22ES Performance Test Record
RF Network Analyzers
Frequency Accuracy
Frequency Point
Minimum
Specifications
Results
Maximum
Specifications
Measurement
Uncertainty
a
13.5 (8719ET/ES) 13.499865 GHz ________________ 13.500135 GHz
±2.35 kHz
20.0 (8720ET/ES) 19.999800 GHz ________________ 20.000200 GHz
±3.00 kHz
26.0 (8722ET/ES) 25.999740 GHz ________________ 26.000260 GHz
±3.60 kHz
a
The measurement uncertainty is based on equipment specified in “Service Test Equipment,” on
page 1-3.
Level Accuracy
Model Type Minimum PORT 1 or REFLECTION Maximum Measurement
Uncertainty
a
Min. Max.
8719ES
8720ES −2.0 dBm ______________ ______________ +2.0 dBm
±0.30 dB
8719ET
8720ET
8719ES (Opt. 007)
8720ES (Opt. 007) +3.0 dBm ______________ ______________ +7.0 dBm
±0.30 dB
8722ES −13.0 dBm
______________
______________ −7.0 dBm
±0.35 dB
8722ET
8722ES (Opt. 007) −8.0 dBm ______________ ______________ −2.0 dBm
±0.30 dB
a
The measurement uncertainty is based on equipment specified in “Service Test Equipment,” on
page 1-3.
