Agilent Technologies 8719ET Service Guide

2-48 Service Guide
System Verification and Performance Tests 8719ET/20ET/22ET
Performance Test Record 8719ES/20ES/22ES
RF Network Analyzers
Source Linearity
Power Level and Model Type
Minimum
Specification
Results
Maximum
Specification
Measurement
Uncertainty
Min. Max.
P
1
8719ET/ES, 8720ET/ES
8719ES Opt. 007,
8720ES Opt. 007
−0.35 dB _______ _______ 0.35 dB
±0.03 dB
8722ET/ES, 8722ES Opt. 007
Freq. range (0.05 − 20 GHz)
−0.35 dB _______ _______ 0.35 dB
±0.03 dB
8722ET/ES, 8722ES Opt. 007
Freq. range (20 − 40 GHz)
−0.60 dB _______ _______ 0.60 dB
±0.03 dB
P
2
8719ET/ES, 8720ET/ES
8719ES Opt. 007,
8720ES Opt. 007
−0.60 dB _______ _______ 0.60 dB
±0.04 dB
8722ET/ES, 8722ES Opt. 007
Freq. range (0.05 − 40 GHz)
−0.60 dB _______ _______ 0.60 dB
±0.04 dB
P
3
8719ET/ES, 8720ET/ES
8719ES Opt. 007,
8720ES Opt. 007
−0.35 dB _______ _______ 0.35 dB
±0.03 dB
8722ET/ES, 8722ES Opt. 007
Freq. range (0.05 − 20 GHz)
−0.35 dB _______ _______ 0.35 dB
±0.03 dB
P
4
8719ET/ES, 8720ET/ES
8719ES Opt. 007,
8720ES Opt. 007 −1.0 dB _______ _______ 1.0 dB
±0.04 dB
