Agilent InfiniiVision 3000 X-Series Oscilloscopes User's Guide 7
Contents
InfiniiVision 3000 X-Series Oscilloscopes—At a Glance 3
In This Guide 5
1 Getting Started
Inspect the Package Contents 23
Install the Optional LAN/VGA or GPIB Module 26
Tilt the Oscilloscope for Easy Viewing 26
Power-On the Oscilloscope 27
Connect Probes to the Oscilloscope 28
Maximum input voltage at analog inputs 28
Do not float the oscilloscope chassis 29
Input a Waveform 29
Recall the Default Oscilloscope Setup 29
Use Auto Scale 30
Compensate Passive Probes 32
Learn the Front Panel Controls and Connectors 33
Front Panel Overlays for Different Languages 40
Learn the Rear Panel Connectors 42
Learn the Oscilloscope Display 43
Access the Built-In Quick Help 45
